- Bundle includes: 2 Rockford Fosgate P2D4-12 12” Subwoofer - DVC (dual 4-Ohm), 400 Watts Rms, 800 Watts Peak
- Dual linear spider with embedded 16 AWG tinsel leads
- Custom 10-AWG nickel plated push terminals
- Features C.L.E.A.N. Set-up
- Optional remote Punch Level Control (PLC2) ready (w/ input clip indicator)
Rockford Fosgate - Two P2D4-12 12" Subwoofers - DVC (dual 4-Ohm), 400 Watts Rms, 800 Watts Peak - This bundle includes 2 Rockford Fosgate P2D4-12 12” Subwoofer - DVC (dual 4-Ohm), 400 Watts Rms, 800 Watts Peak, a pry kit, and a Creative Audio coozy.
Rockford Fosgate P2D4-12 12” Subwoofer - DVC (dual 4-Ohm), 400 Watts Rms, 800 Watts Peak
Features:
Dual linear spider with embedded 16 AWG tinsel leads
Custom 10-AWG nickel plated push terminals
Extended pole piece and bumped vented backplate
High-temp voice coil with spun-laced Nomex re-inforcement collar
Protective PVC textured magnet cover
Kevlar fiber reinforced paper cone
StampCast basket with integrated spider venting
Diamond cut cast aluminum trim ring with optional grille
1 Year Warranty
Specifications
Size: 12"
Power Handling (Watts RMS): 400 Watts RMS, 800 Watts Max
Speaker Connector: Dual 10 AWG compression
Shipping Weight: 15.6 Lbs. (7.07 kg)
Qes: 0.59
Qms: 6.30
Cutout Diameter: 11.22 in. (285 mm)
Re (Ohms): 6.40
Nominal Impedance: Dual 4-Ohm
Voice Coil Diameter: 2.25" (57.15 mm)
Mounting Depth: 6.40 in. (162 mm)
SPL (dB @ 1w/1m): 86
Fs (Hz): 27.2
Qts: 0.54
Vas (Liters): 81.5
Xmax (mm): 13.3
Woofer Displacement: 0.085 cu. ft. (2.4 Liters)
Le (mH): 5.5
Magnet Weight (oz): 72.8 oz. (2.06 kg.)
Sd (cm2): 570
Subwoofer Type: Standard
Voice Coil Type: Dual Voice Coil
Sealed Box Volume (Vb): 1.02 cu. ft. (28.8 Liters)
Vented Box Volume (Vb): 1.79 cu. ft. (50.6 Liters)
